This sound box hailer unit it adopted 24 chip voice coil 80mm magnetic steel,the bass unit it adopted 38 chip voice coil 120mm magnetic steel,high HD definition,plump bass.It suitable for the school authorities,multi-media conference room,product promotion,small-sized sound performance etc
↘Frequency response: 70Hz-18KHz
↘Sensitivity(1 watt/m):93dB±2dB (1W/1m)
↘The maximum sound pressure level(calculate by per meter): 110dB(SPL peak/1m)
↘Continued power: 100W
↘Peak value output power: 200W
↘Hailer unit:1 inch compressed driveX1
↘Bass unit:10 inch X1
↘Resistance：8Ω
↘Connector:6.35
↘Size(long×wide×high）：340×320×510mm
↘Net weight ：12kg
↘Adapter using amplifier power:200W
S3101
Two frequency division single 10 inch sound box
This sound box hailer unit it adopted 24 chip voice coil 80mm magnetic steel,the bass unit it adopted 38 chip voice coil 120mm magnetic steel,high HD definition,plump bass.It suitable for the school authorities,multi-media conference room,product promotion,small-sized sound performance etc
↘Frequency response: 70Hz-18KHz
↘Sensitivity(1 watt/m):93dB±2dB (1W/1m)
↘The maximum sound pressure level(calculate by per meter): 110dB(SPL peak/1m)
