DS 50

DS-50 Digital audio former

↘With sound box processor functional Cara OK impression, each part function can be adjusted independently

↘With 2Bit data bus and 32 Bit DSP

↘The music with 7 sections parametric equalizer. The music to the main output high pass filter：12dB/24dB(0Hz - 303Hz)

↘The microphone with 15 sections parametric equalizer. With microphone press limit function

↘The main output with 5 sections parametric equalizer. With compression limiter

↘Mid output, post output and ultra low with 3 sections parametric equalizer

↘The microphone with 4 feedback inhibition feedback: OFF ?1 ?2 ?3。

↘Can save 16 kind of mode

↘The microphone output, main output, mid output, ultra low sound output, post output with press limit and time delay function

↘The built-in administrator mode and user mode, the user mode can't save after adjust the parameter.

↘This host with full function menu ,it can through the powerful PC interface setting

↘The maximum input level：4V(RMS)

↘The maximum output level:4V(RMS)

↘The music channel gain: MAX：12dB

↘The microphone sensitivity:64mV (Out：4V)

↘S/N:>80dB

↘The input voltage:~220V 50Hz
